New York City has many zoning districts and subdistricts, each with its own rules and regulations governing property development within the district. R9-1 is one example of a residential zoning district in NYC.
R9-1 is a high-density Residential Zoning District in New York City. You can find R9-1 Zoning Districts in Manhattan and Queens.
I am Jorge Fontan, an architect in New York and owner of Vinculum Architecture, a Manhattan-based architecture firm. At Vinculum, we work on a variety of project types, from property and zoning analysis to complete building designs for new developments. In this article, I will review some of the basics of the New York City Zoning District R9-1.
R9-1 Zoning
Multiple New York City Zoning Districts, such as R9-1, have fixed height limits and mandatory setbacks. The City of Yes significantly modified the rules under the New York City Zoning for Housing Opportunity amendment. This article reflects those modifications.
Qualifying Affordable Housing Option
Developers planning projects in an R9-1 Zoning District have the option to construct a strictly market-rate building or to incorporate Qualifying Affordable Housing units. While different zoning regulations and bulk rules apply to each approach, the inclusion of affordable housing allows for a larger overall development, including an increased Floor Area Ratio (FAR) and a higher maximum building height. There are also modified regulations for Qualifying Senior Housing.
R9-1 Zoning Commercial Overlay
When a residential district includes a commercial overlay (e.g., C1 or C2), the zoning permits local retail and services within the residential district.
This designation provides flexibility: developers can construct a purely commercial building, a residential building, or a mixed-use building combining both functions. It is crucial to note that the zoning regulations—particularly regarding Floor Area Ratio (FAR) and building bulk — vary significantly between the commercial and residential portions of a development.
R9-1 Zoning & Community Facility Use
The R9-1 Zoning District is primarily residential, but you can develop community facility uses (such as schools, medical facilities, and certain non-profits) as-of-right.
Key considerations for the development of a Community Facility in an R9-1 Zone include:
- Different Regulations: When you develop a site with community facility use, the specific bulk regulations (including Floor Area Ratio and height limits) may differ from those for standard residential buildings.
- Mixed-Use Options: Developers may also construct a mixed-use building that combines both residential and community facility components.
R9-1 Zoning Regulation Basics
Lot Size:
- Minimum Lot width =18 Feet
- Minimum Lot Area = 1,700 Sq Ft
For Single or Two Family Detached Developments the Lot Size is:
- Minimum Lot Width = 25 Feet
- Minimum Lot Area = 2,375 sq ft
Floor Area Ratio (FAR) on a Narrow Street:
- FAR = 9
- Qualifying Affordable Housing FAR = 10.8
Yards for Zero Lot Line or Detached Buildings:
- Corner Lot: No Yards Required
- Interior Lot = 20 foot minimum rear yard required below a height of 75 feet
- Interior Lot = 30 foot minimum rear yard required above a height of 75 feet
Yards for attached and Semi-Detached Buildings:
- Corner Lot: No Yards Required
- Interior Lot with a Width Less than 40 feet = 30 foot minimum rear yard required below a height of 75 feet
- Interior Lot with a Width of 40 feet or more = 20 foot minimum rear yard required below a height of 75 feet
- Interior Lot = 30 foot minimum rear yard required above a height of 75 feet
Lot Coverage:
- Corner Lot = 100%
- Interior or Through Lot = 80%
Density Factor
Density Factor (Also known as Dwelling Unit Factor) does not apply to all areas of NYC
- 680
Base Height Street: This indicates a setback is required at these heights.
- Base Height = 60 Minimum / 125 Maximum
- Qualifying Affordable Housing Base Height = 60 Minimum / 155 Maximum
A setback is required in the base height range. Or this can be the maximum height of the building without a setback.
Building Height Street: This is the maximum building height.
- Building Height: = 175 feet
- Qualifying Affordable Housing Building Height: =215 feet
Parking in R9-1
The new City of Yes for Housing Opportunity zoning changes have now drastically reduced parking requirements in New York City. There are currently no parking requirements for the Inner Transit Zone, and reduced parking requirements in the Outer Transit Zone, which can be waived under certain conditions.
R9-1 Zoning Districts:
R9-1 Zoning
New York City zoning is complicated and has many special circumstances. This post is intended to provide a brief general overview of R9-1 zoning. This article is not a substitute for the New York City Zoning Resolution.
